Max. RPM: 12000
Max. RCF: 14800 x g
Capacity: 24/12 capillaries
Temp. Control: N/A
Product Catagories
Products > Special Purpose Centrifuges
Hematocrit Centrifuge
Model: TG12M/TG12
|
Features
- Microprocessor-based controlled and DC brushless motor drived for smooth running and low noise.
- Parameters can be modified during running with no need to stop.
- In automatic RCF/PRM mode, you can set runs to a desired speed or g-force and moniter them in real time.
- Remaining time is displayed in seconds when it is less than 1 minute.
- Designed with various protection devices and fault diagnosis system for maximum operational safety, such as lid lock system, over-speed detection and so on.
Specifications
| Hemotocrit Centrifuge??ith rotor | ||
| Model | TG12M | TG12 |
| Max.Speed (r/min) | 12000 | 12000 |
| Max. RCF (x g) | 14800 | 14800 |
| Max. Capacity | 24 x 75mm capillaries | 12 x 75mm capillaries |
| Control | Microprocessor | Microprocessor |
| Drive | DC Brushless Motor | DC Brushless Motor |
| Speed Range (r/min) | 100-12000 | 100-12000 |
| Speed Control Accuracy (r/min) | ±30 | ±30 |
| Timer Range(min) | 1-99 | 1-99 |
| Noise (dB) | ≤ 62 | ≤ 62 |
| Power Supply V (Hz) | 220/110 (50/60),5A single phase | 220/110 (50/60),5A single phase |
| Dim. (W x D x H) mm | 325 x 400 x 240 | 325 x 400 x 240 |
| Weight (kg) | 25 | 25 |
Rotors
| Rotor Type | Rotor No. | Capacity |
Max. Speed (rpm) |
Max. RCF (x g) |
Main Unit |
| Hemotocrit Rotor | 1 | 12 capillaries | 12000 | 14800 | TG12 |
| Hemotocrit Rotor | 2 | 24 capillaries | 12000 | 14800 | TG12M |
